WebEDI API Documentation

Revision History

Date	Module	Description	Related Documentation
2024/07/15	Despatch Advice	Added Send Despatch Advice API;	Send Despatch Advice API
2024/07/29	Despatch Advice	Added Body request parameter fields	Added interface fields See Request Parameters Description.
2024/09/12	Despatch Advice	Modified Date format; Added Body request parameter fields	Added interface fields See Request Parameters Description.
2024/10/17	Despatch Advice	Added ASN number parameter field	Added interface fields See Request Parameters Description.
2024/12/20	API Request Example	Added login authorization interface; 增加接口 API Request Example；
2024/12/26	Order Details	Added order list API; Added order query API	Order List API Order Details API Order Query API
2025/03/20	Invoice	Added Send Invoice API;	Send Invoice API
2025/04/10	Send Delivery Note	Added Send Delivery Note API;	Send Delivery Note API
2025/05/27	Party Address	Added Party Address Information API;	Party Address Information API

Login authorization, used to obtain access_token parameter

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/auth/token
Request Method	POST

Request Parameters

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
admin	String	Username	Yes	xxx
password	String	Password	Yes	xxx

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	Failed to obtain token.
access_token	String	Token	eyJhbGciOi...
expiration	Number	Token Validity Period (Unit: seconds)	28800
expired_at	Number	Token Expiration Timestamp	1704508394000

Return Example

Normal Return Example

json5

{
    "access_token": "eyJhbGciOi...",
    "success": true,
    "expiration": 28800,
    "expired_at": 1704508394000
}

Error Return Example

json5

{
    "code": 403,
    "success": false,
    "message": "Failed to obtain token.",
}

API Request Example

Order List - Main Order Information Only (Paginated Query)

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/order/page
Request Method	POST

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink
pagination	Object	Pagination Parameters	Yes
pagination.current	Number	Current Page	Yes	1
pagination.pageSize	Number	Page Size	Yes	20

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data
data.records	Array	Order Data Collection

data.records Parameter Description

Parameter Name	Type	Description	Example Value	Description
serial_number	String	Serial Number	135963345397353472	Unique order identifier
document_number	String	Document Number	1300001	Customer sent document number
document_type	String	Message Type	850	Customer sent Message Type: 850-Purchase Order; 860-Purchase Order Change; 830-Long-term Forecast Order; 862-Short-term Forecast Order;
order_number	String	Order Number	10193220643

API Request Example

Order List - Including Order Details (Paginated Query)

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/order/pageInfo
Request Method	POST

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink
date	String	Query Date	No	2025-11-06	Query by order receive date, Date format: yyyy-MM-DD, Default: Current Date
document_type	String	Message Type	No	DELFOR	Query by Message Type, default empty (query all types)
current	Number	Current Page	No	1	Default value: 1
page_size	Number	Page Size	No	100	Default value: 100

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data
data.records	Array	Order Data Collection
data.total	Number	Total
data.size	Number	Page Size
data.current	Number	Current Page

data.records Parameter Description

Parameter Name	Type	Description	Example Value	Description
Serial_Number	String	Serial Number	135963345397353472	Unique order identifier
Document_Number	String	Document Number	1300001	Customer sent document number
Document_Type	String	Message Type	850	Customer sent Message Type: 850-Purchase Order; 860-Purchase Order Change; 830-Long-term Forecast Order; 862-Short-term Forecast Order;
...	String	Other parameters are business parameters, related to actual business

API Request Example

Order Details (Query by Serial Number)

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/order/info/{serial_number}
Request Method	GET

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Path Parameters

Parameter Name	Description	Description	Required	Example Value	Description
serial_number	String	Serial Number	Yes	135963345397353472	Unique order identifier

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data
data.document_data	Array	Document/Order Data Content

data.document_data Parameter Description

Parameter Name	Type	Description	Example Value	Description
Sender_Id	String(36)	Sender ID Identifier	958755
Sender_Internal_Id	String(36)	Sender Internal ID Identifier	LM485	Not required, can be empty
Document_Type	String(36)	Message Type	850	Customer sent Message Type: 850/ORDERS-Purchase Order; 860/ORDCHG-Purchase Order Change; 830/DELFOR-Long-term Forecast Order; 862/DELJIT-Short-term Forecast Order;
Document_Number	String(36)	Document Number	1300001	Customer sent document number
Document_Datetime	String(36)	Message Date/Time	20240509	Customer sent Message Date Format: CCYYMMDD or CCYYMMDDHHmm
Purchase_Order_Number	String(36)	Purchase Order Number	10193220643
Purchase_Order_Date	String(36)	Purchase Order Date	20240509	Purchase Order Date Format: CCYYMMDD
Buyer_Id	String(36)	Buyer/Purchaser Code
Buyer_Agency_Code	String(10)	Buyer/Purchaser CodeType
Buyer_Name	String(70)	Buyer/Purchaser Name
Buyer_Address	String(36)	Buyer/Purchaser Address
Buyer_Address_Info	String(36)	Buyer/Purchaser Detailed Address
Buyer_Street	String(256)	Buyer/Purchaser Street
Buyer_City	String(36)	Buyer/Purchaser City
Buyer_State_Province	String(36)	Buyer/Purchaser State/Province Code
Buyer_Postcode	String(18)	Buyer/Purchaser Postal Code
Buyer_Country	String(10)	Buyer/Purchaser Country/Region Code
Seller_xxx	String	Seller/Vendor Information		Refer to Buyer parameters
Ship_From_xxx	String	Ship From Information		Refer to Buyer parameters
Ship_To_xxx	String	Ship To Information		Refer to Buyer parameters
Bill_To_xxx	String	Bill To Information		Refer to Buyer parameters
Sold_To_xxx	String	Sold To Information		Refer to Buyer parameters
Currency_Code	String(10)	Currency Code	USD	Required for Invoice 810
Detail_Items. Detail_Item_Loop	Array	Material Data Collection

Detail_Items.Detail_Item_Loop Parameter Description

Parameter Name	Type	Description	Example Value	Description
Line_Item_Number	String(6)	Line Item Number	00010
Buyer_Item_Number	String(36)	Buyer/Purchaser Item Number	PA123456
Purchase_Order_Number	String(70)	Purchase Order号	991935452615
Purchase_Order_Line _Number	String(6)	Order Line Number	00010
Unit_Price	String(18)	Unit Price	163.12	Required for Invoice 810
Unit_Price_Basis_Code	String(3)	Unit Price Basis Code	PN	(PE) Price per Each (PN) Price per Ten (HP) Price per Hundred (TP) Price per Thousand
Place_Of_Delivery	String(256)	Place of Delivery	ED05	Required for Despatch Advice DESADV
Place_Port_Discharge	String(256)	Place/Port of Discharge Code	WEDJ	Required for Despatch Advice DESADV
Additional_Internal _Destination	String(256)	Additional Internal Destination Code	3256	Required for Despatch Advice DESADV
Item_Description	String(256)	Description Information
Delivery_Schedule_Number	String(70)	Delivery Schedule Number	392
Delivery_Schedule_Date	String(36)	Delivery Schedule Date	Format: CCYYMMDD or CCYYMMDDHHmm
Plan_Items. Plan_Item_Loop	Array	预测/Order Data Collection

Plan_Items.Plan_Item_Loop Parameter Description

Parameter Name	Type	Description	Example Value	Description
Delivery_Plan_Status	String(10)	Delivery Plan Status Code	4	1-Firm 4-Planning/forecast
Delivery_Plan_Status_View	String(256)	Delivery Plan Status Description	Planning/forecast	1-Firm 4-Planning/forecast
Discrete_Quantity	String(36)	Delivery Quantity	162	Forecast/Order Quantity
Discrete_Unit	String(8)	Quantity Unit	EA
Outstanding_Quantity	String(36)	Outstanding Quantity	0	Outstanding Quantity (Backorder)
Quantity_To_Be_Delivered	String(36)	Pending Delivery Quantity	0	Pending Delivery Quantity
Request_Delivery_Date	String(36)	Buyer Requested Delivery Date	20250529	Format: CCYYMMDD or CCYYMMDDHHmm

Response Example

json5

{
  "data": {
    "document_number": "20250426150038",
    "document_data": {
      "Sender_Id": "000987654321",
      "Sender_Type": "ZZZ",
      "Sender_Internal_Id": "",
      "Receiver_Id": "O01234567890",
      "Receiver_Type": "ZZZ",
      "Receiver_Internal_Id": "",
      "Number": "27041508",
      "Test_Indicator": "",
      "Serial_Number": "1365985846678032384",
      "Document_Type": "DELFOR",
      "Document_Number": "20250426150038",
      "Document_Datetime": "202504270257",
      "Document_Date_Format": "203",
      "Expiry_Date": "20251217",
      "Validity_Start_Date": "202504270257",
      "Effective_From_Date": "202504270257",
      "Effective_To_Date": "20251217",
      "Delivery_Schedule_Number": "20250426150038",
      "Buyer_Id": "PO001",
      "Buyer_Agency_Code": "92",
      "Buyer_Name": "",
      "Buyer_Address": "",
      "Buyer_Address_Info": "",
      "Buyer_Street": "",
      "Buyer_City": "",
      "Buyer_State_Province": "",
      "Buyer_Postcode": "",
      "Buyer_Country": "",
      "Seller_Id": "QA002",
      "Seller_Agency_Code": "92",
      "Seller_Address": "",
      "Seller_Address_Info": "",
      "Seller_Name": "",
      "Seller_Street": "",
      "Seller_City": "",
      "Seller_State_Province": "",
      "Seller_Postcode": "",
      "Seller_Country": "",
      "Ship_From_Id": "",
      "Ship_From_Agency_Code": "",
      "Ship_From_Address": "",
      "Ship_From_Address_Info": "",
      "Ship_From_Name": "",
      "Ship_From_Street": "",
      "Ship_From_City": "",
      "Ship_From_State_Province": "",
      "Ship_From_Postcode": "",
      "Ship_From_Country": "",
      "Ship_To_Id": "",
      "Ship_To_Agency_Code": "",
      "Ship_To_Address": "",
      "Ship_To_Address_Info": "",
      "Ship_To_Name": "",
      "Ship_To_Street": "",
      "Ship_To_City": "",
      "Ship_To_State_Province": "",
      "Ship_To_Postcode": "",
      "Ship_To_Country": "",
      "Detail_Items": {
        "Detail_Item_Loop": [
          {
            "Line_Item_Number": "",
            "Buyer_Item_Number": "8579552554",
            "Purchase_Order_Number": "9958745411225",
            "Purchase_Order_Line_Number": "",
            "Calculation_Date": "202504270257",
            "Place_Port_Discharge": "WEDJ",
            "Additional_Internal_Destination": "3256",
            "Plan_Items": {
              "Plan_Item_Loop": [
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "28",
                  "Discrete_Unit": "EA",
                  "Quantity_To_Be_Delivered": "28",
                  "Request_Delivery_Date": "202505161200"
                },
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "50",
                  "Discrete_Unit": "EA",
                  "Request_Delivery_Date": "202505181200"
                },
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "200",
                  "Discrete_Unit": "EA",
                  "Quantity_To_Be_Delivered": "200",
                  "Request_Delivery_Date": "202512171200"
                }
              ]
            }
          },
          {
            "Line_Item_Number": "",
            "Buyer_Item_Number": "8579552998",
            "Purchase_Order_Number": "9958745411225",
            "Purchase_Order_Line_Number": "",
            "Calculation_Date": "202504270257",
            "Place_Port_Discharge": "TUYS",
            "Additional_Internal_Destination": "TUYS",
            "Plan_Items": {
              "Plan_Item_Loop": [
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "162",
                  "Discrete_Unit": "EA",
                  "Quantity_To_Be_Delivered": "162",
                  "Request_Delivery_Date": "202512151200"
                },
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "162",
                  "Discrete_Unit": "EA",
                  "Quantity_To_Be_Delivered": "162",
                  "Request_Delivery_Date": "202512161200"
                },
                {
                  "Delivery_Plan_Status": "4",
                  "Delivery_Plan_Status_View": "Planning/forecast",
                  "Discrete_Quantity": "162",
                  "Discrete_Unit": "EA",
                  "Quantity_To_Be_Delivered": "162",
                  "Request_Delivery_Date": "202512171200"
                }
              ]
            }
          }
        ]
      }
    }
  },
  "code": 0,
  "message": null,
  "success": true
}

API Request Example

Order Query (Query by Order Number)

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/order/info/order/{order_number}?project_key={project_key}
Request Method	GET

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Path Parameters

Parameter Name	Description	Description	Required	Example Value	Description
order_number	String	Order Number	Yes	10193220643	If there are duplicate orders, get the most recent order by default

Request Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink

Return Parameters

Refer to Order Details (Query by Serial Number)

API Request Example

Create Despatch Advice

💡

Through the API interface, submit offline shipping information to the EDI system, which generates 856 or DESADV messages and sends them to customers.

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/delivery/saveData
Request Method	POST

Request Parameters

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink
action_type	String	Send Message Type Identifier	Yes	delivery	Fixed value
content	Json	Send Message Content	Yes

content Parameters

Parameter Name	Description	Description	Required	Example Value	Description
despatch_datetime	String	Despatch Date/Time	Yes	20240627	Format: CCYYMMDD
delivery_datetime	String	Delivery Date/Time	No	20240715	Format: CCYYMMDD
estimated_arrival_date	String	Estimated Arrival Date/Time	Yes	20240715	Format: CCYYMMDD
bill_of_lading	String	Bill of Lading Number	Yes	PL123456987
packing_list_number	String	Packing List Number	Yes	PL2404120011
carrier_gross_weight	Number	Shipment Gross Weight (Unit: KG)	Yes	520.00	Total gross weight of all goods in ASN (accurate to two decimal places)
carrier_net_weight	Number	Shipment Net Weight (Unit: KG)	No	480.00	Total net weight of all goods in ASN (accurate to two decimal places)
weight_unit	String	Weight Unit	Yes	KG
quantity_of_pack	String	Quantity of Packages	Yes	33
package_type	String	Package Type	Yes	PCK90
carrier_bill_number	String	Carrier Number	No	CN00001
carrier_scac	String	Carrier SCAC Code	No	UPSN	Generally consists of four letters
transport_mode	String	Transport Mode	No	A	(A) Air (AE) Air Express (LT) Less than trailer load (M) Motor (Full truck) (R) Rail (SE) Sea
equipment_unit	String	运输设备代码 (Equipment Description Code)	No	TL	(CN) Container (RR) Railcar (TE) Trailer (TL) Trailer (not otherwise specified)
equipment_initial	String	Equipment Initial/Prefix	Yes	UPSN
equipment_number	String	Equipment Number (Truck/Container No.)	Yes	200003211	Customoer transport equipment number
ship_from_party_id	String	Ship From ID	Yes		According to agency_code parameter, generally 92, provided by customer (buyer)
ship_from_party_name	String	Ship From Name	Yes
ship_from_agency_code	String	Ship From Agency Code Type	Yes	91	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
ship_from_address	String	Address	Yes
ship_from_address_info	String	Detailed Address	No
ship_from_city_name	String	City	No
ship_from_state_province_code	String	State/Province Code	No
ship_from_postal_code	String	Postal Code	No
ship_from_country_code	String	Country/Region Code	No
ship_to_party_id	String	Ship To ID	Yes		According to agency_code parameter, generally 92, provided by customer (buyer)
ship_to_party_name	String	Ship To Name	Yes
ship_to_agency_code	String	Ship To Agency Code Type	Yes	92	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
ship_to_address	String	Address	Yes
ship_to_address_info	String	Detailed Address	No
ship_to_city_name	String	City	No
ship_to_state_province_code	String	State/Province Code	No
ship_to_postal_code	String	Postal Code	No
ship_to_country_code	String	Country/Region Code	No
no_packages.no_packages_loop	Array	Product Details

no_packages_loop Parameters

Parameter Name	Description	Description	Required	Example Value	Description
no_package_type	String	Package Type	Yes	PCK90
no_package_type_agency_code	String	Package Type Code	Yes	92	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
quantity_of_pack	String	Quantity of Packages	Yes	33
package_gross_weight	String	Package Net Weight	Yes	15
package_net_weight	String	Package Gross Weight	No	13
weight_unit	String	Weight Unit	Yes	KG
purchase_order_number	String	Purchase Order Number	Yes	5526931007
purchase_order_date	String	Order Date	Yes	20240706	Format: CCYYMMDD
line_items.line_item_loop	Array	Material Details	Yes

line_item_loop Parameters

Parameter Name	Description	Description	Required	Example Value	Description
buyer_item_number	String	Buyer/Purchaser Item Number	Yes	89519892
seller_catalog_number	String	Seller Catalog Number	Yes	PK10001
quantity	Number	Despatch Quantity	Yes	8808	Quantity of materials in package (integer)
quantity_unit	String	Quantity Unit	Yes	EA
order_line_number	String	Order Line Number	Yes	00010	Item line number from Purchase Order
country_origin	String	Country of Origin	Yes	CN

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data
data.serial_number	String	Delivery Note Serial Number	1360053108683337728

Examples

Request Example

This is a request example under general configuration. Optional fields can be set to empty strings.

json5

{
  "project_key": "ChinLink",
  "action_type": "delivery",
  "content": {
    "despatch_datetime": "20250218",
    "delivery_datetime": "",
    "estimated_arrival_date": "20250228",
    "bill_of_lading": "PL00001",
    "carrier_gross_weight": "407.2",
    "weight_unit": "KG",
    "package_type": "PCK90",
    "quantity_of_pack": "33",
    "quantity_unit": "EA",
    "carrier_bill_number": "CN00001",
    "transport_mode": "A",
    "carrier_scac": "UPSN",
    "no_packages": {
      "no_package_loop": [
        {
          "no_package_type": "PCK90",
          "no_package_type_agency_code": "92",
          "quantity_of_pack": "12",
          "package_gross_weight": "15",
          "weight_unit": "KG",
          "purchase_order_number": "5526931007",
          "purchase_order_date": "20240706",
          "line_items": {
            "line_item_loop": [
              {
                "buyer_item_number": "89519892",
                "seller_catalog_number": "PK10001",
                "quantity": "8808",
                "quantity_unit": "EA",
                "order_line_number": "00010",
                "country_origin": "CN"
              }
            ]
          }
        },
        {
          "no_package_type": "PCK90",
          "no_package_type_agency_code": "92",
          "quantity_of_pack": "11",
          "package_gross_weight": "15",
          "weight_unit": "KG",
          "purchase_order_number": "5526931008",
          "purchase_order_date": "20240706",
          "line_items": {
            "line_item_loop": [
              {
                "buyer_item_number": "89519893",
                "seller_catalog_number": "PK10002",
                "quantity": "8720",
                "quantity_unit": "EA",
                "order_line_number": "00010",
                "country_origin": "CN"
              }
            ]
          }
        }
      ]
    },
    "ship_from_party_id": "1001",
    "ship_from_agency_code": "91",
    "ship_from_address": "Fenghui South Road, High tech Zone",
    "ship_from_address_info": "1107B, Building B, Huajing Plaza, No. 20",
    "ship_from_party_name": "Xi'an ChinLink Technology Co., Ltd.",
    "ship_from_city_name": "Xi'an",
    "ship_from_street": "",
    "ship_from_state_province_code": "XA",
    "ship_from_postal_code": "710075",
    "ship_from_country_code": "CN",
    "ship_to_party_id": "1101",
    "ship_to_agency_code": "92",
    "ship_to_address": "Ship To Address",
    "ship_to_address_info": "Ship To Address Info",
    "ship_to_party_name": "Ship To Name",
    "ship_to_city_name": "Ship To City",
    "ship_to_street": "",
    "ship_to_state_province_code": "",
    "ship_to_postal_code": "111000",
    "ship_to_country_code": "US"
  }
}

Return Example

Normal Return Example

json5

{
    "success": true,
    "message": "",
    "data": {
        "serial_number": "1360053108683337728",
    }
}

Error Return Example

json5

{
    "status": false,
    "message": " Failed message."
}

API Request Example

Create Invoice

💡

Through API interface, submit offline Invoice info via API to EDI system, generating 810 or INVOIC messages and sending to customers.

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/delivery/saveData
Request Method	POST

Request Parameters

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink
action_type	String	Send Message Type Identifier	Yes	invoice	Fixed value
content	Json	Send Message Content	Yes

content Parameters

Parameter Name	Description	Description	Required	Example Value	Description
purchase_order_number	String	Purchase Order Number	Yes	10193220643
purchase_order_date	String	Order Date	Yes	20240627	Format: CCYYMMDD
invoice_number	String	Invoice Number	Yes	20240715120603
total_invoice_amount	Number	Total Invoice Amount	Yes	547.04
currency_code	String	Currency Code	Yes	USD
trade_tax_type_code	String	Trade Tax Type Code	No	LS	(LS) State and Local Sales Tax
trade_tax_amount	String	Tax Amount	No
ship_to_party_id	String	Ship To ID	Yes
ship_to_party_name	String	Ship To Name	Yes
ship_to_agency_code	String	Ship To Agency Code Type	Yes	92	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
ship_to_address	String	Address	Yes
ship_to_address_info	String	Detailed Address	No
ship_to_city_name	String	City	No
ship_to_state_province_code	String	State/Province Code	No
ship_to_postal_code	String	Postal Code	No
ship_to_country_code	String	Country/Region Code	No
bill_to_party_id	String	Bill To ID	Yes
bill_to_party_name	String	Bill To Name	Yes
bill_to_agency_code	String	Bill To Agency Code Type	Yes	92	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
bill_to_address	String	Address	Yes
bill_to_address_info	String	Detailed Address	No
bill_to_city_name	String	City	No
bill_to_state_province_code	String	State/Province Code	No
bill_to_postal_code	String	Postal Code	No
bill_to_country_code	String	Country/Region Code	No
invoice_issuer_party_id	String	Invoice Issuer ID	Yes
invoice_issuer_party_name	String	Invoice Issuer Name	Yes
invoice_issuer_agency_code	String	Invoice Issuer Agency Code Type	Yes	91	(91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent
invoice_issuer_address	String	Address	Yes
invoice_issuer_address_info	String	Detailed Address	No
invoice_issuer_city_name	String	City	No
invoice_issuer_state_province_code	String	State/Province Code	No
invoice_issuer_postal_code	String	Postal Code	No
invoice_issuer_country_code	String	Country/Region Code	No
invoice_items.invoice_item_loop	Array		Yes
spac_items.spac_item_loop	Array		No

invoice_items.invoice_item_loop Parameters

Parameter Name	Description	Description	Required	Example Value	Description
line_item_number	String	Line Item Number	Yes	00010	Item line number from Purchase Order
buyer_part_number	String	Buyer/Purchaser Item Number	Yes	5800000001
quantity_invoiced	String	Quantity Invoiced	Yes	32
quantity_unit	String	Quantity Unit	Yes	EA
unit_price	String	Unit Price	Yes	16.47
unit_price_basis_code	String	Unit Price Basis Code	Yes	PE	(PE) Price per Each (PN) Price per Ten (HP) Price per Hundred (TP) Price per Thousand
invoice_item_amount	String	Invoice Item Amount	Yes	527.04

spac_items.spac_item_loop Parameters

Parameter Name	Description	Description	Required	Example Value	Description
allowance_charge_indicator	String	Allowance or Charge Type	Yes	C	(A) Allowance (C) Charge (N) No Allowance or Charge (P) Promotion (Q) Charge Request (R) Allowance Request (S) Service
service_charge_type	String	Charge Type (Service, Promotion, Allowance or Charge)	Yes	D500	(C310) Discount (D240) Freight (D500) Handling
service_charge_amount	String	Service Charge Amount	Yes	20

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data
data.serial_number	String	Delivery Note Serial Number	1360053108683337728

Examples

Request Example

This is a request example under general configuration. Optional fields can be set to empty strings.

json5

{
  "project_key": "ChinLink",
  "action_type": "invoice",
  "content": {
    "purchase_order_number": "10193220643",
    "purchase_order_date": "20240627",
    "invoice_number": "20240715120603",
    "total_invoice_amount": "520.04",
    "currency_code": "USD",
    "invoice_items": {
      "invoice_item_loop": [
        {
          "line_item_number": "00010",
          "buyer_part_number": "5800000001",
          "quantity_invoiced": "32",
          "quantity_unit": "EA",
          "unit_price": "16.47",
          "unit_price_basis_code": "PE",
          "invoice_item_amount": "527.04"
        }
      ]
    },
    "spac_items": {
      "spac_item_loop": [
        {
          "allowance_charge_indicator": "C",
          "service_charge_type": "D500",
          "service_charge_amount": "20"
        }
      ]
    },
    "ship_to_party_id": "1101",
    "ship_to_agency_code": "92",
    "ship_to_address": "Ship To Address",
    "ship_to_address_info": "Ship To Address Info",
    "ship_to_party_name": "Ship To Name",
    "ship_to_city_name": "Ship To City",
    "ship_to_street": "",
    "ship_to_state_province_code": "",
    "ship_to_postal_code": "111000",
    "ship_to_country_code": "US",
    "bill_to_party_id": "1102",
    "bill_to_agency_code": "92",
    "bill_to_address": "Bill To Address",
    "bill_to_address_info": "Bill To Address Info",
    "bill_to_party_name": "Bill To Name",
    "bill_to_city_name": "Bill To City",
    "bill_to_street": "",
    "bill_to_state_province_code": "NL",
    "bill_to_postal_code": "111222",
    "bill_to_country_code": "MX",
    "invoice_issuer_party_id": "1001",
    "invoice_issuer_agency_code": "91",
    "invoice_issuer_address": "Fenghui South Road, High tech Zone",
    "invoice_issuer_address_info": "1107B, Building B, Huajing Plaza, No. 20",
    "invoice_issuer_party_name": "Xi'an ChinLink Technology Co., Ltd.",
    "invoice_issuer_city_name": "Xi'an",
    "invoice_issuer_street": "",
    "invoice_issuer_state_province_code": "XA",
    "invoice_issuer_postal_code": "710075",
    "invoice_issuer_country_code": "CN"
  }
}

Return Example

Normal Return Example

json5

{
    "success": true,
    "message": "",
    "data": {
        "serial_number": "1360053108683337728",
    }
}

Error Return Example

json5

{
    "status": false,
    "message": " Failed message."
}

API Request Example

Send Delivery Note (Despatch Advice/Invoice)

💡

Submit created Despatch Advice or Invoice via API to EDI system for transmission.
Message transmission is processed asynchronously.

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/file/action/delivery
Request Method	POST

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Body Parameters

Parameter Name	Description	Description	Required	Example Value	Description
project_key	String	Project Key	Yes	ChinLink	Project Key assigned by ChinLink
action_type	String	Send Message Type	Yes	send-inv	send-inv: Send Invoice send-asn: Send Despatch Advice
serial_number	String	Delivery Note Serial Number	Yes	1355079589866352640	Delivery Note Serial Number returned when creating Despatch Advice or Invoice

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx

Return Example

Normal Return Example

json5

{
  "data": true,
  "code": 0,
  "message": null,
  "success": true
}

Error Return Example

json5

{
    "data": null,
    "code": 500,
    "message": "Please configure the root directory of the project.",
    "success": false
}

Party Address Information List

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/location/list
Request Method	GET

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Array	Returned Address Information Collection

data Parameter Description

Parameter Name	Type	Description	Example Value	Description
location_id	String	Address Information ID	24	Unique Address Information Identifier
party_id	String	Party ID Identifier	1001
party_name	String	Party Name	Xi'an ChinLink Technology Co., Ltd.
agency_code	String	Agency Code (Identifies Party Information Source)	92	(1) D-U-N-S Number, Dun & Bradstreet (9) D-U-N-S+4, D-U-N-S Number with Four Character Suffix (10) ODETTE (14) UCC/EAN Location Code Prefix (16) DUNS (91) Assigned by seller or seller's agent (92) Assigned by buyer or buyer's agent (ZZ) Mutually Defined
address	String	Address Information	Fenghui South Road, High tech Zone	Max 35 characters
address_info	String	Address Information Details	1107B, Building B,	Max 35 characters
street	String	Street Information	Huajing Plaza, No. 20
city_name	String	City Name	Xi'an
state_province_code	String	State/Province Code	XA
postal_code	String	Postal Code	710065
country_code	String	Country/Region Code	CN	E.g., CN, US, HK

API Request Example

Party Address Information (Query by ID)

Request Description

Request Address	https://xxx.xxx.xxx.xxx:8481/api/location/info/{location_id}
Request Method	GET

Request Parameters

Bearer Auth Authentication Parameters

Parameter Name	Description	Description	Required	Example Value	Description
access_token	String	Token	Yes	eyJhbGciOi...	Obtained via Login Authorization Interface

Header Parameters

Parameter Name	Description	Description	Required	Example Value	Description
Return-Type	String	Interface Return Type	Yes	DocumentData	Fixed value

Path Parameters

Parameter Name	Description	Description	Required	Example Value	Description
location_id	String	Address Information ID	Yes	44	Unique Address Information Identifier

Return Parameters

Parameter Name	Type	Description	Example Value	Description
status	Boolean	Return Status	true	true or false
message	String	Return Message	xxx
data	Object	Return Data

data Parameter Description

Refer to data Parameter Description in Party Address Information List API documentation.

Return Example

json5

{
  "data": {
    "location_id": 24,
    "name": "ChinLink",
    "party_id": "1001",
    "party_name": "Xi'an ChinLink Technology Co., Ltd.",
    "agency_code": "92",
    "address": "Fenghui South Road, High tech Zone",
    "address_info": "1107B, Building B",
    "street": "Huajing Plaza, No. 20",
    "city_name": "Xi'an",
    "state_province_code": "XA",
    "postal_code": "710065",
    "country_code": "CN"
  },
  "code": 0,
  "success": true
}

WebEDI API Documentation ​

Login Authorization Interface ​

Request Description ​

Request Parameters ​

Body Parameters ​

Return Parameters ​

Return Example ​

API Request Example ​

Order List - Main Order Information Only (Paginated Query) ​

Request Description ​

Request Parameters ​

Bearer Auth Authentication Parameters ​

Header Parameters ​

Body Parameters ​

Return Parameters ​

data.records Parameter Description ​

API Request Example ​

Order List - Including Order Details (Paginated Query) ​

Request Description ​

Request Parameters ​

Bearer Auth Authentication Parameters ​

Header Parameters ​

Body Parameters ​

Return Parameters ​

data.records Parameter Description ​

API Request Example ​

Order Details (Query by Serial Number) ​

Request Description ​

Request Parameters ​

Bearer Auth Authentication Parameters ​

Header Parameters ​

Path Parameters ​

Return Parameters ​

data.document_data Parameter Description ​

Detail_Items.Detail_Item_Loop Parameter Description ​

Plan_Items.Plan_Item_Loop Parameter Description ​

Response Example ​

API Request Example ​

Order Query (Query by Order Number) ​

Request Description ​

Request Parameters ​

Bearer Auth Authentication Parameters ​

Header Parameters ​

Path Parameters ​

Request Parameters ​

Return Parameters ​

API Request Example ​

Create Despatch Advice ​

Request Description ​

Request Parameters ​

Body Parameters ​

content Parameters ​

no_packages_loop Parameters ​

line_item_loop Parameters ​

Return Parameters ​

Examples ​

Request Example ​

Return Example ​

API Request Example ​

Create Invoice ​

Request Description ​

Request Parameters ​

Body Parameters ​

content Parameters ​

invoice_items.invoice_item_loop Parameters ​

spac_items.spac_item_loop Parameters ​

Return Parameters ​

Examples ​

Request Example ​

Return Example ​

API Request Example ​

Send Delivery Note (Despatch Advice/Invoice) ​

Request Description ​

Request Parameters ​

Bearer Auth Authentication Parameters ​

Body Parameters ​

Return Parameters ​

Return Example ​

Party Address Information List ​

Request Description ​

WebEDI API Documentation

Login Authorization Interface

Request Description

Request Parameters

Body Parameters

Return Parameters

Return Example

API Request Example

Order List - Main Order Information Only (Paginated Query)

Request Description

Request Parameters

Bearer Auth Authentication Parameters

Header Parameters

Body Parameters

Return Parameters

data.records Parameter Description

API Request Example

Order List - Including Order Details (Paginated Query)

Request Description

Request Parameters

Bearer Auth Authentication Parameters

Header Parameters

Body Parameters

Return Parameters

data.records Parameter Description

API Request Example

Order Details (Query by Serial Number)

Request Description

Request Parameters

Bearer Auth Authentication Parameters

Header Parameters

Path Parameters

Return Parameters

data.document_data Parameter Description

Detail_Items.Detail_Item_Loop Parameter Description

Plan_Items.Plan_Item_Loop Parameter Description

Response Example

API Request Example

Order Query (Query by Order Number)

Request Description

Request Parameters

Bearer Auth Authentication Parameters

Header Parameters

Path Parameters

Request Parameters

Return Parameters

API Request Example

Create Despatch Advice

Request Description

Request Parameters

Body Parameters

content Parameters

no_packages_loop Parameters

line_item_loop Parameters

Return Parameters

Examples

Request Example

Return Example

API Request Example

Create Invoice

Request Description

Request Parameters

Body Parameters

content Parameters

invoice_items.invoice_item_loop Parameters

spac_items.spac_item_loop Parameters

Return Parameters

Examples

Request Example

Return Example

API Request Example

Send Delivery Note (Despatch Advice/Invoice)

Request Description

Request Parameters

Bearer Auth Authentication Parameters

Body Parameters

Return Parameters

Return Example

Party Address Information List

Request Description
